Ikeda 9TS MC cartridge
We think
The Ikeda 9TS is a truly special pickup because it brings the pinnacle of Japanese pickup engineering to a price range that is accessible to significantly more music lovers. It embodies everything you'd expect from an Ikeda: sonic immediacy, full-bodied imaging, deep emotional response, and precise technical execution . With its comparatively high output voltage of 0.35 millivolts, it's more practical than the more expensive Ikeda pickups and thus more universally applicable. At the same time, it remains a true Ikeda—handcrafted, uncompromising in materials, and bearing the clear signature of Isamu Ikeda. The 9TS makes it clear: even entry into the Ikeda world doesn't mean a compromise product, but rather the full essence of a sound philosophy cultivated over decades.
Product presentation
The Ikeda 9TS is a moving-coil (MC) cartridge positioned as the entry-level model in Ikeda's 9 Series. Its housing is made of low-resonance aluminum , combining stability with tonal neutrality. The cantilever is made of two-layer duralumin , a material used in aerospace engineering, characterized by its rigidity, light weight, and excellent resonance control. At its tip sits an oval-cut diamond , enabling high tracking accuracy while simultaneously delivering smooth, musical reproduction.
Technically, the 9TS impresses with 0.35 millivolt output voltage , 6 ohm internal resistance , 2 grams of recommended tracking force , a stylus compliance of 7 µm/mN , and an impressive frequency response of 10 to 45,000 Hertz . With a weight of just 10 grams, it's ideal for a variety of medium to heavy tonearms.
It thus meets all the expectations that a discerning music lover could have of an MC cartridge in this class – and in some respects even goes beyond them.
Special features
What makes the Ikeda 9TS special is its balance between technical excellence and musical character. Many pickups in this price range tend to sound analytical or overly emphatic. The 9TS, on the other hand, combines fine detail and naturalness with a powerful bass foundation and generous spatial imaging .
The 0.35 millivolt output voltage is a real advantage: While many MC systems deliver extremely low levels, which absolutely require very high-quality, low-noise MC preamps, the 9TS can be easily integrated into significantly more setups. This makes it universal and practical.
Its duralumin cantilever contributes significantly to the controlled yet musical sound. Duralumin is stiffer than aluminum, yet lighter than many other materials—a perfect balance for precise signal transmission. The oval, full diamond cut, in turn, provides a high contact area with the groove, reducing distortion while simultaneously producing a harmonious, rounded sound character.
Technology & Materials
The MC technology of the 9TS is based on Isamu Ikeda's decades of experience. In an MC (moving coil) system, the coils move in the magnetic field while the magnet remains stationary. This significantly reduces the moving mass and enables finer, more precise tracking than with MM systems. The disadvantage—a lower output voltage—is mitigated in the 9TS by the comparatively high 0.35 millivolts.
The coils of the 9TS are carefully wound to create the most linear magnetic field possible. The magnet assembly is robust and delivers consistent performance. The aluminum housing not only provides mechanical stability but also dampens resonance. Combined with the duralumin cantilever and diamond, this results in a highly precise yet musical signature that is typical of Ikeda.
Sustainability & Manufacturing
The Ikeda 9TS, like all Ikeda products, is entirely handcrafted in Japan . Each cartridge undergoes rigorous quality controls, and even the smallest tolerances are checked. This level of craftsmanship ensures longevity and consistent quality .
Another aspect is maintainability : Even though MC cartridges are generally not user-repairable, Ikeda traditionally offers factory service. This makes the 9TS a sustainable investment—far removed from the throwaway mentality of many of today's products.
Technical data (specs)
System: Moving Coil (MC)
Output voltage: 0.35 mV (1 kHz, 35.4 mm/s)
Internal resistance: 6 Ω
Tracking force: 2.0 g ±0.2 g
Needle compliance: 7 µm/mN
Weight: 10 g
Frequency response: 10 – 45,000 Hz
Channel separation: > 27 dB (1 kHz)
Channel equality: ±1 dB (1 kHz)
Stylus: oval cut full diamond
Cantilever: Duralumin, double layer
Test reports / press reviews
The German magazine LP (issue 3/2020) attests to the Ikeda 9TS's excellent value for money, particularly highlighting its exceptional spatial imaging . Vocals are reproduced with body and depth , while instruments are stable and clearly positioned in the room. The powerful bass reproduction , which is both precise and musical, was particularly praised.
In conclusion, Holger Barske writes:
"The Ikeda 9TS impresses with its balanced, powerful sound, excellent spatial imaging, and practical output voltage. An MC cartridge that sets standards in its class in terms of sound and is the perfect entry point into the Ikeda world."
This positions the 9TS as a leading cartridge in its price range – a real insider tip for music lovers looking for a system that combines authenticity, dynamics and musicality .
Background / History / Development
The 9TS is part of the renowned Ikeda 9 Series , which is available in several configurations. While higher-end models like the 9TT and 9Gss utilize even finer diamond cuts and other materials, the 9TS remains the model that conveys Ikeda's character at an attractive price.
Isamu Ikeda , the founder, is considered a pioneer of MC cartridge construction in Japan. Back in the 1960s, he developed legendary tonearms and cartridges at Fidelity Research that still hold benchmark status today. With the founding of Ikeda Sound Laboratories in 2000, he continued this tradition – with uncompromising products that emphasize the purist standards of analog music reproduction. The 9TS carries on this legacy and makes it accessible to a wider audience.
